| Housing | Stainless steel 1.4404 (316L), IP68 |
| Certificates | CE, ATEX, CSA, FM |
| Process Temperature Range | -40°C to +200°C |
| Pressure Range | +3bar max. |
| Supply Voltage | 24V DC (max. 30V DC) up to max. 550Ohm loop resistance. |
| Measuring Range | 40m/100m |
| Lens Material | PEI (40m)/PEEK (100m) |
| Signal Output | 4 .. 20mA, 2-Wire |
| Communication | HART, Profibus PA and via Foundation Fieldbus |
| Measuring Conditions | DK >1,6 |
| Process Connection | Flat flange 3"/80mm, 4"/100mm, 6"/150mm in stainless steel 1.4301 (304), 1.4404 (316L) or with adjustable fitting in coated aluminium. |
| Programming | Via display and programming buttons, hand programmer and infrared interface or via HART interface and FDT/Simatic PDM |
