| Housing | Aluminium IP66, NEMA Type 4/4X |
| Certificates | ATEX, IEC-Ex, FM, CSA, INMETRO, EHEDG; also GasEx approval with the selection of flameproof housings, |
| Functional Safety | SIL 2 |
| Process Temperature | -40°C to +1100°C |
| Pressure Range | -0,9bar to +10bar |
| Sensitivity | min. 15g/l - adjustable in 3 settings |
| Process Connection | G1", G1¼" and G1½"; NPT 1", NPT 1¼" and NPT1½"; M30x1,5 and M32x1,5; Triclamp 2"; Flanges DN100 PN16, other flanges available |
| Process Connection Material | Aluminium or stainless steel 1.4305 (303), 1.4301 (304), 1.4541 (321L) or 1.4404 (316L) |
| Measuring Vane & Shaft Material | Stainless steel 1.4301 (SS304),1.4305 (303) or 1.4404 (316L) |
| Bearing | Encapsulated ball bearing dustproof, optional stainless steel; radial shaft seal in NBR rubber, FPM or PTFE |
| Supply Voltage | AC: 24V / 48V/ 115V/ 230V (50-60Hz); DC: 24V; Universal electronics 24V DC / 22...230V AC |
| Output Signal | Microswitch, Relay SPDT contact; Relay DPDT contact. |
| Switchable Signal Output | FSH / FSL with Universal Voltage integrated; with AC electronics as an available option. |
| Signal Delay | With Universal Voltage Electronic and PNP is an integrated adjustable time delay of the signal output. |
| Fail Safe Alarm | Optional for Universal Voltage electronics; monitoring of motor / transmission / electronics / power failure / line break. |
