| Housing | Aluminium or plastic PA6, IP66 |
| Certificates | ATEX, IEC-Ex, TR-CU, INMETRO |
| Process Temperature Range | -40°C to +80°C |
| Pressure Range | -0,9bar to +0,8bar |
| Sensitivity | min. 15g/l - adjustable in 3 settings |
| Process Connection | G1½"; NPT1½" |
| Process Connection Material | Aluminium or stainless steel 1.4305 (303) |
| Measuring Vane & Shaft Material | Stainless steel 1.4301 (SS304),1.4305 (303) or 1.4404 (316L) |
| Bearing / Seal | Dust-proof ball-bearing, optional in stainless steel, radial shaft seal in NBR rubber, FPM or PTFE. |
| Supply Voltage | AC: 24V / 48V/ 115V/ 230V (50-60Hz); DC: 24V; Universal Voltage 24V DC / 22...230V AC; PNP 24V DC |
| Signal Output | Microswitch, Relay SPDT contact; PNP open collector. |
| Switchable Signal Output | FSH / FSL with Universal Voltage and PNP integrated; AC electronics available as an option. |
| Signal Delay | With Universal Voltage electronics and PNP is an integrated adjustable time delay of the signal output. |
| Failsafe Alarm | Optional for Universal Voltage electronics; Monitoring of motor / transmission / electronics / power failure / line break. |
