| Housing | Aluminium or PA6 plastic, IP66 |
| Certificates | ATEX, IEC-Ex, TR-CU, INMETRO |
| Process Temperature Range | -40°C to +250°C |
| Pressure Range | -0,9bar to +10bar |
| Sensitivity | min. 15g/l - adjustable in 3 settings |
| Process Connection | Flange DN100 PN16, more flanges available |
| Process Connection Material | Aluminium or stainless steel 1.4301 (304), 1.4541 (321L) |
| Extension Material | Aluminium or stainless steel1.4301 (SS304),1.4305 (303) |
| Bearing/Seal | Dust-proof ball-bearing, optional in stainless steel, radial shaft seal in NBR rubber, FPM or PTFE |
| Supply Voltage | AC: 24V / 48V/ 115V/ 230V (50-60Hz); DC: 24V; Universal Voltage 24V DC / 22...230V AC; PNP 24V DC |
| Signal Output | Microswitch, Relay SPDT contact; PNP open collector |
| Switchable Signal Output | FSH / FSL with Universal Voltage and PNP integrated; with AC electronics as available option. |
| Signal Delay | With Universal Voltage Electronic and PNP is an integrated adjustable time delay of the signal output. |
| Fail Safe Alarm | Optional for Universal Voltage Electronics; Monitoring of motor / transmission / electronics / power failure / line break. |
